XLSpecialized Trailers XL Lightweight 13 West Coast
Detailed Specs
XLSpecialized Trailers
XL Lightweight 13 West Coast
Additional Information
Trailer
65’ 9”
120”
14’ 3”
59”
16”
115”
10’ wide, 30’ long
6"
26”
60”
16’ 1/2” x 7” brakes
disc brakes
21’ 6”
25,000 lb air ride
3
8.25 x 22.5 steel rims
275/ 70R / 22.5 tires
12v sealed Grote harness
rubber mounted led lights
2 tail light package
1 mid-turn signal per side
2 clearance light per side
7 pole electrical socket
2 pair d-rings
overall length: 18’ 11”
overall width: 120”
(3) 30,000 lb nominal
60” axle spacing
15’ 1” spread from last axle on trailer
to first axle on booster
spring brakes on 1 axle
limit chains on all axles
polymer wheel covers
25,000 lb air ride
air bag shut off
manual ride height control
raise and lower valve
2 pair d-rings
overall length: 37’ 3”
overall width: 120”
14’ 4” long
16” & 24” kingpin settings
135” & 127” swing clearance
49” 5th wheel height
heavy-duty 2 speed landing gear
bump up ramps to hat box 5th wheel
13HP power unit
hydraulic hat box
54” to 72” loaded 5th wheel height
(3) 30,000 lb nominal
60” axle spacing
spring brakes on 1 axle
limit chains on all axles
polymer wheel covers
black, IH red, CAT yellow or white
air & electric done after paint
non-standard paint colors
non-standard metallic paint
5 year structural
3 year paint
XL LW 13: 170 MG 3+3+3
Description
Use XL’s Lightweight 13 Axle, a multi-axle combination of a Jeep, Mechanical Gooseneck Trailer, and a Booster, to carry wind turbine nacelles. The trailer is rated with a capacity of 170,000 pounds in 10 feet concentrated. It features a 10-foot wide, 30-foot long main deck for secure hauling of the largest loads as well as a detachable wheel area for the addition of deck sections if needed.
