Detailed Specs
XLSpecialized Trailers
XL KNIGHT: 80 MFG
Additional Information
Trailer
48’
102"
mechanical detachable full-width
10’ long
1 pair pull out lights
49”
16”
84”
29’
6”
18”
swing out outriggers
"1 pair pull out lights
battery back up with 4-way plug"
54"
16 1/2” x 7” brakes
2 pair spring brakes
9’
"1 pair pull out lights
battery back up with 4-way plug"
25,000 lb air ride
raise and lower valve
manual ride height control
(2) 25,000 lb nominal
8.25 x 22.5 steel inside, aluminum
polished outside rims
255 / 70R / 22.5 tires
12V sealed Grote harness
rubber mounted LED lights
3 tail light package with
aluminum cover
4” amber strobe as 3rd tail light
black
air & electric done after paint
5 year structural
3 year paint
Description
The XL Mechanical Full-width Gooseneck is the ideal mechanical solution for hauling agricultural equipment. Built with XL quality for longevity and effectiveness, the XL MFG (also referred to as RGN: Removable Gooseneck) meets your agricultural and everyday commercial hauling needs with ease. The XL 80 MFG, the market’s most trusted double drop trailer, is packed with standard features. It is available with swingout outriggers or with aluminum pullout outriggers for moving agricultural equipment. The XL MFG: Mini-Deck is yet another option for those needing to haul taller loads. It features a 12-inch loaded deck height with a light 3-beam deck design.
