XLSpecialized Trailers XL 80 Slide Axle
Detailed Specs
XLSpecialized Trailers
XL 80 Slide Axle
Additional Information
Trailer
48’, 51’ or 53’
102"
10’ 5”
length: 37’ 7”, 40’ 7”, 42’ 7:
5th wheel height other than
49”
28hp unit with dual hydraulics
mark V 2 speed landing gear
hydraulic park stands
15,000 lb hydraulic planetarty drive
winch with 1/2” cable &
loop
30,000 lb hydraulic planetary drive
winch with 9/16” cable & loop
air kickout for winch
6 function wireless winch remote
7 function wireless remote, for use with
air kickout option
10 function wireless remote, for use
with air kickout & dock levelers
registration holder
49"
21"
82"
T-1 flange, 80K web
(4) fabricated i-beams
38"
9’ wide
10’ wide
dock levelers
stake pockets alternating with chain
slots on 12 “ centers, outer
beams
additional bent d-rings
pan-style d-rings
drop down d-rings
amber strobe as third taillight
50"
12 1/4” x 7 1/2” brakes
auto slack adjusters
25,000 lb air ride
manual dump valve
liquid filled air gauge
Air-Weigh digital scale
2
60” axle spacing
chassis uni lube system
cam covers
hubometer
dust shields
spring brakes on 2nd axle
6.75 x 17.5 steel rims
245 / 70R / 17.5 tires
235/75R/17.5 tires
245/70R/17.5 michelin tires
255/70R/22.5 16pr radial
(deck height + 4.5”)
PSI tire inflation system
aluminum polished wheels
aluminum Durabright wheels
12V sealed Grote harness
rubber mounted LED lights
2 tail light package with
aluminum cover
2 clearance lights per side
1 mid-turn light per side
7 pole electric socket
black, IH red, CAT yellow or white
air & electric done after paint
non-standard paint colors
non-standard metallic paint
5 year structural
3 year paint
XL 80 SA
XL 80 SA: California legal
XL 80 SA: R-tac legal
XL 110 SA
Description
Slide Axle Trailers are a rigid gooseneck trailer with axles that slide forward, enabling the whole main deck of the trailer to tilt down creating a ramp on the rear. The tilted deck creates a low-degree loading angle. Combined with a winch and roller system on the gooseneck, this design is optimal for the towing industry.
