XLSpecialized Trailers XL 80 Sentinel: Slide Axle
Detailed Specs
XLSpecialized Trailers
XL 80 Sentinel: Slide Axle
Additional Information
Trailer
53’
102"
10’ 5”
24hp unit with dual hydraulics,
top mount
30,000 lb hydraulic winch with 100’
of 5/8” cable
6 function wireless winch remote
bolt-on winch guard
49"
21”
82"
T-1 flange, 80K web
(4) fabricated i-beams
38”
50"
12 1/4” x 7 1/2” brakes
25,000 lb air ride
80: (2) 25,000 lb nominal
liquid filled air gauge
manual dump valve on all axles
6.75 x 17.5 steel rims inside
aluminum polished outside rims
245 / 70R / 17.5 tires
12V sealed Grote harness
rubber mounted LED lights
3 tail light package with
aluminum cover
amber strobe as 3rd tail light
(4) 3/4” LED clearance lights per side
1 mid-turn light per side
7 pole electric socket
black
air & electric done after paint
5 year structural
3 year paint
Description
Slide Axle Trailers are a rigid gooseneck trailer with axles that slide forward, enabling the whole main deck of the trailer to tilt down creating a ramp on the rear. The tilted deck creates a low-degree loading angle. Combined with a winch and roller system on the gooseneck, this design is optimal for the towing industry.
