XLSpecialized Trailers XL 80 Power Tail
Detailed Specs
XLSpecialized Trailers
XL 80 Power Tail
Additional Information
Trailer
48’ or 53’
102"
9’
13HP Honda power unit
30,000 lb winch
bolt-on winch guard
10 function wireless remote
49"
16"
86"
T-1 flange, 80k web
48’ OAL: 30’ 4” long
53’ OAL: 35’ 4” long
13’ 8” hydraulic tail:
8’ 8” platform
60” fold under flip tail
automatic flip tail lock
traction aids
star traction plate decking
10 degree load angle
steel tread plate decking in lieu of star
plate
36"
double drop design
additional d-rings
49"
spring brakes on 2 axles
12 1/4” x 7 1/2” brakes
25,000 lb air ride
2
hubometer
TP axles (same inner & outer bearings)
dust shields
cat eye systems
disc brakes
6.75 x 17.5 steel rims
245 / 70R / 17.5 tires
255 tires changes rear
deck height to 39”
aluminum mill wheels
*aluminum polished wheels (outside)
customer specified tires
customer specified mud flaps
Michelin tires
PSI tire inflation system
12V sealed Grote harness
rubber mounted led lights
3 tail light package
1 mid-turn signal per side
2 clearance light per side
7 pole electrical socket
*amber strobe as 3rd tail light
additional clearance lights
black, IH red, CAT yellow or white
air & electric done after paint
custom paint colors
metallic paint colors
5 year structural
3 year paint
Description
XL’s Power Tail trailer features the hydraulic folding tail for loading onto the rear. Easily load a variety of equipment or static loads using the winch and ramp. Benefit from XL’s unique user-friendly features such as the self-cleaning traction plate decking and lug-style tail hinge which prevents debris from accumulating.
