XLSpecialized Trailers XL 100 SD

Name: XLSpecialized Trailers XL 100 SD - Ballard
SKU: XL 100 SD

Stock: XL 100 SD Category: Drop Deck Trailers Last Updated: 06/25/2025 02:08 PM

Calculate financing

Stock: XL 100 SD

Model: XL 100 SD

Request More Info

Is this still available ?
What's the vehicle's history ?
How many people owned previously ?
Ask us a specific question !

Detailed Specs

Manufacturer:

XLSpecialized Trailers

Model:

XL 100 SD

Additional Information

Concentrated Capacity:

Trailer

OVERALL LENGTH:

48"

OVERALL WIDTH:

102"

GOOSENECK:

10'

5TH WHEEL HEIGHT:

49"

KING PIN SETTING:

16"

SWING CLEARANCE:

84"

MAIN DECK:

38"

GROUND CLEARANCE:

LOADED DECK HEIGHT:

39 1/2”

AXLE SPACING:

10’ 1”

BRAKES:

17 1/2” x 7” brakes

SUSPENSION:

25,000 lb air ride

AXLES:

WHEELS & TIRES:

8.25 x 22.5 steel rims 255 / 70R / 22.5 tires

LIGHTING:

12V sealed Grote harness rubber mounted LED lights 2 tail light package with aluminum cover 2 clearance lights per side 1 mid-turn light per side 7 pole electric socket

PAINT:

black, IH red, CAT yellow or white air & electric done after paint

PAINT OPTIONS:

non-standard paint colors non-standard metallic paint

WARRANTY:

5 year structural 3 year paint

AVAILABLE MODELS:

XL 70 SD XL 80 SD XL 90 SD XL 100 SD XL 110 SD XL 120 SD XL 130 SD

Description

XL Step Decks are constructed from 100k flange and 80k webs, using XL’s one-piece construction, for superior strength and durability. Deck heights range from 33 inches to 40 inches to fit your needs. Step Decks are available with many ramp options on the rear, from beaver tails to large hydraulic bi-fold ramps.
