XLSpecialized Trailers XL 100 Power Tail
Detailed Specs
XLSpecialized Trailers
XL 100 Power Tail
Additional Information
Trailer
48’ or 53’
102"
9’
13HP Honda power unit
30,000 lb winch
bolt-on winch guard
10 function wireless remote
49"
16"
86"
T-1 flange, 80k web
48’ OAL: 30’ 4” long
53’ OAL: 35’ 4” long
13’ 8” hydraulic tail:
8’ 8” platform
60” fold under flip tail
automatic flip tail lock
traction aids
star traction plate decking
steel tread plate decking in lieu of star
plate
36"
double drop design
additional d-rings
49"
spring brakes on 2 axles
12 1/4” x 7 1/2” brakes
25,000 lb air ride
2
hubometer
TP axles (same inner & outer bearings)
dust shields
cat eye systems
disc brakes
6.75 x 17.5 steel rims
245 / 70R / 17.5 tires
255 tires changes rear
deck height to 39”
aluminum mill wheels
*aluminum polished wheels (outside)
customer specified tires
customer specified mud flaps
Michelin tires
PSI tire inflation system
12V sealed Grote harness
rubber mounted led lights
3 tail light package
1 mid-turn signal per side
2 clearance light per side
7 pole electrical socket
*amber strobe as 3rd tail light
additional clearance lights
black, IH red, CAT yellow or white
air & electric done after paint
custom paint colors
metallic paint colors
5 year structural
3 year paint
Description
XL’s Power Tail trailer features the hydraulic folding tail for loading onto the rear. Easily load a variety of equipment or static loads using the winch and ramp. Benefit from XL’s unique user-friendly features such as the self-cleaning traction plate decking and lug-style tail hinge which prevents debris from accumulating.
